Alpha 86
Alpha 86 - front
Alpha 86 Fuses – Purchase on our web store by part number:
Micro fuse, 0.25 Amp 125V, Part Number FSX-X130
Alpha 86 T/R Board
Alpha 86 Switches – Available from Mouser or Digikey.:
86 OPR/STBY, HI/LO
Alpha p/n SQR-X109
Digikey EG1528-ND
Mouser 612-R5CBLKBLKEF0
86 ON, OFF
Alpha p/n SQR–X110
Digikey R5EBLKBLKEF0-ND
Documentation
| 86 Operating and Technical Manual (ABX-X123 Cntl Brd without latest updates) | Alpha_86_Operating_and_Technical_Manual |
| 86 Parts list | PARTS_LIST_-_ALPHA_86 |
| 86 Schematics, First Version (AB-090 Cntl Brd) | Alpha_86_Original_Version_AB-090 |
| 86 Tuneup Procedure | 86_tuneup |
| 86 Tubedeck Blower Replacement | 78_76A_374A_86_blower_replacement_1 |
| Alpha Amplifier Production Dates | Alpha_Amplifier_Production_Dates |
| Alpha Amplifier Keying Specs | Amp_Keying_Specs |
